DESCRIPTION

Liquid ring vacuum pumps.

Typical applications:
▪ Corrosive, toxic, noxious and carcinogenic gases
▪Hydrocarbons, pyrophorics other flammables gases



MAIN FEATURES
  • Cast casing and Impeller in AISI316, Titanium, Hastelloy C;
  • Cast Iron/Carbon Steel bracket (VPL & VPM only)
  • No contact between internal rotating parts, except for mechanical seal rings (pumps mod. VPS and VPL) and rotating bushes (pump VPM magnetic drive);
  • No need for external lubrication source to operate;
  • Easy maintenance;
  • Design temperature 100°C;
  • Pressure rating NP 10;
OPTIONAL

• Automatic drain and anti-cavitation valves;
• Graphite/ceramic mechanical seal;
• Oil lubricated ball bearing (only VPL).

Available materials of construction: AISI 316, 316 L, ALLOY 20, HASTELLOY – C, TITANIUM

TECHNICAL DATA 50 HZ 60 HZ
Flow 50÷450 m3/h 260÷2350 GPM
Max Head 33 mbar 28,2 inchesHg
Temp 0°/ 90° C 32°/+170° F
Mawp 10 BAR 150 PSI
Industries served
Refinery, chemical, petrochemical, pharmaceutical, paper mills, textile industry, food processing, sugar plants, dairies, electronics, water treatment plants, any hazardous chemical applications.
